OMEFLEX rubber foam insulation—sheet products
OMEFLEX rubber foam insulation used butyronitrile rubber and polyvinyl chloride NBR/PVC with best performance as main raw material and other high quality auxiliary material through foaming and other special procedure.This product has perfect performances such as soft anti-bending cold-resistant heat-resisting fire-blocking water-proof low thermal conductivity and sound-absorption. It can be widely used for every kind of cold/hot mediumpiping and containers in central control air condition construction chemical industry medicine vehicle electrical
apparatus and other fields to reduce cold/thermal loss. OMEFLEX rubber foam insulation was deeply loved by themasses of customers.
Product Technical Indicators
| Item | specification | standard | |
| type of material | Flexible rubber foam material | GB/T 17794-2008 | |
| appearance | black | ||
| foam structure | Completely closed bubble | ||
| kg/m3 Density | ≤95 | GB/T 6343 | |
| Oxygen index | ≥32％ | GB/T 2406 | |
| SDR | ≤75 | GB/T 8627 | |
| water vapor permeability |
≤0.034 -20℃time ≤0.031 40℃time ≤0.036 |
GB/T 10294 | |
| water vapor permeability | ≤2.8×10-11 | GB/T 17146-1997 | |
| coefficient | |||
| factor |
≥7.0×103 |
||
| ％ water absorption ratio in vacuum |
≤10 |
GB/T 17794-2008 | |
| Flammability | Combustible B1 | GB 8624-1997 | |
|
When used in the construction field, it is not less than C When the product is used in the construction sector, the level is not less than C-class |
GB 8624-2006 | ||
| Toxicity of combustion and tobacco production Toxicity of smoke from burning | ZA3 Safety grade Security level | GA 132-1996 | |
| dimensional stability ％ 105℃±3℃，7d Dimension stability | ≤10 | GB 8811 | |
| N/cm Crack resistance | ≥2.5 | GB/T 10808 | |
| Compression resilience ratio， Compression ratio | ≥70 | GB/T 6669-2001 | |
|
Anti-ozone 202mPa,200h anti-ozone |
Not cracking | GB/T 7762 | |
| 150h Aging resistance |
slightly crumpling ，no cracks , no pin holes , not deforming |
GB/T 16259 | |
| Temperature range | -40-110 | GB/T 17794 | |
Products Specifications
| Thickness | 10mm | 15mm | 20mm | 25mm | 30mm |
| m/piece | 16m | 16m | 8m | 8m | 8m |
|
Notes: 1. The above specifications are those in common use; special specifications are available at customers' request. |
|||||
Comparison of thickness required for installation
| Environment condition | Insulation pipe size | Suitable thickness (millimeter) under pipe temperature | |||||
| Temperature | Relative humidity | inch | Millimeter | 13℃ | 7℃ | 3℃ | -15℃ |
| 26.5℃ | 50% | 3/8-3 | 10-76 | 10 | 10 | 10 | 15 |
| 3-5 | 76-127 | 15 | 15 | 15 | 15 | ||
| 5-10 | 127-254 | 15 | 15 | 15 | 20 | ||
| 29℃ | 70% | 3/8-3 | 10-76 | 10 | 15 | 15 | 20 |
| 3-5 | 76-127 | 15 | 15 | 15 | 20 | ||
| 32℃ | 80% | 5-10 | 127-254 | 15 | 15 | 15 | 25 |
| 3/8-5 | 10-127 | 15 | 15 | 20 | 20 | ||
| 5-10 | 127-254 | 20 | 25 | 25 | 35 | ||
| 32℃ | 85% | 3/8-1 1/2 | 10-38 | 20 | 25 | 30 | 45 |
| 85% | 38-76 | 20 | 30 | 30 | 50 | ||
| 3-5 | 76-127 | 20 | 30 | 35 | 60 | ||
| 5-10 | 127-254 | 25 | 30 | 40 | 60 | ||
| ＞10 | ＞254 | 30 | 40 | 45 | 70 | ||
| 32℃ | 90% | 1/8-1/2 | 3-13 | 25 | 32 | 35 | 45 |
| 90% | 13-64 | 30 | 35 | 45 | 60 | ||
| 2 1/2-5 | 64-127 | 30 | 35 | 45 | 65 | ||
| 5-10 | 127-254 | 35 | 45 | 50 | 75 | ||
| ＞10 | ＞254 | 35 | 50 | 60 | 75 | ||
2, the relative humidity is bigger, thicker materials;
3, medium temperature is lower, thicker materials;
4. The larger the diameter of the pipe, the thicker the material.
